20-Channel Universal LED Sync Chaser Controller — 5–24V · Heavy-Duty MOSFET · Multi-Board Running Light

🎆 India ka sabse advanced 20-channel running-light chaser — ek naya generation. Powerful MOSFET output, ultra-smooth animation, aur 5V se 24V tak koi bhi single-colour LED. Ab ek se zyada board aapas me SYNC karke chalao — do ya zyada controller bilkul ek jaisa (Mirror), ya kai boards jodkar 40 / 60 / 80 / 100 channel ka ek bada animation jahan light ek board se doosre board tak bilkul smooth travel karti hai.

⭐ Khaas Features

• 🔥 20 Channels single-colour LED output
• ✨ Ultra-Smooth Brightness — next-gen hardware PWM, rock-steady output, sync ke waqt bhi bilkul smooth
• 🔌 Wide Voltage 5–24V DC — 12V ho ya 24V LED, dono chalengi (universal)
• ⚙️ Heavy-Duty MOSFET — har channel 6 Amp tak load, board thanda chalta hai (no heatsink needed)
• 🎞️ 100+ built-in effects — runners, meteors, comets, scanners, wipes, theatre chase, strobe, sparkle & breathing
• 🎚️ Speed + Brightness — do knob (potentiometer) — live fast/slow aur overall dimming
• 🌗 Mood Mode — Full (fast, festival) ya Smooth (slow, elegant — mandir/hotel/wedding) ek switch se
• 🔒 Design Lock with Memory — favourite effect lock; power cut ke baad bhi wahi chalega
• 🔗 Multi-Board SYNC (RS-485) — kai board tak pixel-perfect sync
• 📏 Extended Mode — boards jodkar 40 / 60 / 80 / 100+ channel
• 🪞 Mirror Mode — saare boards ek jaisa show
• 🎛️ 8-pin DIP — aasan board addressing & settings
• 🇮🇳 Made in India — Koshi Electronics quality

💡 Load Capacity (per channel)

Koi bhi single-colour LED load 6 Amp tak per channel — 12V/24V LED strip, 50-LED bunch, LED module, LED bulb. Board me heavy-duty power MOSFET lage hain jo thande chalte hain. Sirf LED-type load — motor/solenoid/coil/inductive load NAHI.

🔗 Sync Modes

🪞 Mirror Mode: 2+ board bilkul same 20-channel pattern — ek jaisa show.
📏 Extended Mode: Board 1 = LED 1–20, Board 2 = 21–40… light poore setup me ek sire se doosre sire tak chalti hai. 2 board = 40ch, 3 = 60ch, 4 = 80ch, 5 = 100ch.
🔌 Sync wiring (RS-485): sabhi boards ka A↔A, B↔B, GND↔GND jodo. Har board ka apna 5–24V power, GND common.

🎛️ Setting Kaise Kare (8-pin DIP)

Board par 8 chhote switch hain — bas inhe ON/OFF karke poori setting hoti hai 👇

   1   2   3   4   5   6   7   8
 ┌───────────────────────────────┐
 │ ▢   ▢   ▢   ▢   ▢   ▢   ▢   ▢ │   ⬅️ DIP Switch
 └───────────────────────────────┘

Har switch ka kaam:

• 🔢 Switch 1–4 = Board number (address) — Master pe total boards, Slave pe uska number
• 🪞 Switch 5 = Mirror (saare board ek jaisa)
• 👑 Switch 6 = Master (OFF) / Slave (ON)
• 🔒 Switch 7 = Design Lock (favourite effect lock)
• 🌗 Switch 8 = Mood — OFF = Full (fast) · ON = Smooth (slow/elegant)

👉 Quick settings:

• 💡 1 Board (20 ch): saare switch OFF ✅
• 🔗 Multi-board: ek board Master (SW6 OFF), baaki Slave (SW6 ON) + address set — light poore chain me smooth chalti hai.
• 🪞 Sab ek jaisa (Mirror): Master → SW5 ON · Slaves → SW6 ON

(Poora DIP chart + step-by-step User Manual product ke saath / launch par milega.)

📦 In the Box

1 × 20-Channel Universal Sync Chaser Board (Heavy-Duty MOSFET) · Instruction card.

❓ FAQ

❓ Isme kaunse LED / load chalte hain?
Sirf LED-type single-colour load — 12V/24V LED strip, 50-LED bunch, LED module, LED bulb. Koi bhi LED load 6 Amp tak per channel. Motor, solenoid, pump, coil ya inductive load ke liye NAHI. RGB/pixel LED ke liye bhi nahi.

❓ Kya 24V LED chalegi?
Haan — ye universal hai, 5V se 24V tak. 12V ho ya 24V LED, dono perfectly chalengi.

❓ Kya isse 220 Volt wali lari / series light chala sakte hain?
❌ Nahi. Ye sirf 5–24V DC ke liye hai. 220V AC lari isse chalegi nahi (aur khatarnak bhi hai).

❓ Brightness smooth hai?
Haan — next-gen hardware PWM se rock-steady, ultra-smooth output, sync ke waqt bhi.

❓ Kitna load daal sakte hain?
Har channel 6 Amp tak single-colour LED load. Isse zyada load na dein.

❓ Power supply kaunsa chahiye?
5–24V DC SMPS (aapke LED voltage ke hisaab se, e.g. 12V ya 24V). Total load ke hisaab se wattage chunein. Bade setup ke liye 2 SMPS bhi laga sakte hain.

❓ 40/60/80/100 channel kaise banau?
Extended mode — boards ko RS-485 se chain karo aur DIP se address set karo. Light poore chain me ek sire se doosre tak smooth chalti hai.

❓ Power cut ke baad setting yaad rehti hai?
Haan — Design Lock (SW7) se lock kiya effect memory me save hota hai, power aane par wahi chalta hai.

❓ Kab available hoga?
🚀 Launching soon. Stock update ke liye "Notify" karein ya Koshi Electronics support se sampark karein.

🇮🇳 Made in India · Koshi Electronics — premium LED controllers & chasers.
