| Type |
WS2812B |
WS2811 |
SK6812 |
WS2815 |
| IC Placement |
Built-in |
External |
Built-in / External |
Built-in |
| Working Voltage |
5VDC |
5/12/24VDC |
5/12/24VDC |
12VDC |
| Data Transmission |
Single signal |
Single signal |
Single signal, dual signal |
Dual signal |
| Refresh Rate |
400 Hz |
800 KHz |
2 MHz |
2 MHz |
| PWM Frequency |
2.25 MHz |
880 Hz |
2.25 MHz |
2.25 MHz |
| Cut Segment |
1-LED |
1-LED /3-LED /4-LED/ 6-LED /12-LED |
1-LED /3-LED |
1-LED |
| LED Color |
RGBIC |
Single white addressable, RGBIC, RGBW addressable, RGBIC+CCT |
Single white addressable, WWA (color temperatures addressable), RGBIC, RGBW addressable |
Single white addressable, RGBIC |
| LED Density |
30/60/72/ 74/96/144 LEDs/m, 160/288/332 chips/m |
30/32/60/72/84/90 /120/144/168/240 LEDs/m, 160/316/240/648/720 chips/m |
30/54/60/72 /74/84/90 /96/120/144 LEDs/m |
30/60/74 /96/144 LEDs/m |
| PCB Width |
3mm /4mm /5mm /10mm /12mm |
4mm /5mm /6mm /7mm /8mm /10mm /12mm /15mm /16mm /20mm /40mm |
3mm /4mm /5mm /7mm /8mm /10mm /11mm /12mm |
10mm /12mm |
| Waterproof Rating |
IP20/65/67/68 |
IP20/65/67/68 |
IP20/65/67/68 |
IP20/65/67/68 |
