▶️ Watch: 20 Port Smart Wi-Fi Pixel LED Parallel Controller Demo
The 20 Port Smart Wi-Fi Pixel LED Parallel Controller is built for shop owners, decorators and event planners who want large, smooth-running multi-language LED name boards and displays — controlled directly from a phone browser, with no app download or PC software needed. It uses true parallel (Z-type) wiring for easy, lag-free assembly and supports scrolling text in Hindi, English, Urdu, Arabic, Marathi, Gujarati, Tamil and other regional languages. Perfect for shop name boards, Diwali Thoran, wedding welcome boards and stage displays.
| Specification | Details |
|---|---|
| Ports | 20 parallel data ports |
| IC support | WS2811 / WS2812B / UCS1903 |
| Wiring layout | Parallel Z-Type (easy frame assembly) |
| Voltage | 5V DC |
| Control | WiFi web portal — phone browser, no app needed |
| WiFi name | W1000_20P_XXXX (default password: 12341234) |
| Control URL | 10.10.10.1 in browser after connecting |
| Languages | Hindi, English, Urdu, Arabic (RTL), Marathi, Gujarati, Tamil & more |
| Matrix sizes | 25x20, 25x40, 50x20, 50x40, 100x20 |
| Playback modes | Text only / Text + Animation / Animation only |
| Best for | Shop name boards, Thoran, wedding welcome boards, stage displays |
The 20-Port Smart Wi-Fi Pixel LED Parallel Controller turns your LED setup into a dynamic multi-language name board or matrix display — controlled entirely from your smartphone. No app to install and no PC software required: connect to the controller's own Wi-Fi network and type your message straight from your mobile browser.
Key Features
- 100% smartphone controlled: connect to the controller's Wi-Fi network and manage everything from your mobile browser — no app, no PC.
- Multi-language scrolling text: display text in English, Hindi, Marathi, Gujarati, Tamil, Urdu, and other regional languages.
- True parallel output (Z-type wiring): multi-port parallel architecture for fast, easy board assembly and smooth, lag-free text and animation.
- Dynamic backgrounds & colours: overlay your message on built-in visual effects; adjust text colour, background colour, and scroll speed instantly.
- Plug & play: connect a 5V supply, plug in your pixel LED strings, connect your phone, and start customising.
Best For
- Shop name boards & digital advertising signs
- Wedding & event welcome boards
- Diwali, Ganpati (Ganesh Chaturthi), Navratri torans, gate arches & festive decor
- DJ lighting & stage backdrops
Specifications
| Specification | Detail |
|---|---|
| Supported LEDs | Standard 3-pin pixel LEDs — WS2811, WS2812B, UCS1903 |
| Wiring layout | Parallel (Z-type) for fast frame assembly |
| Operating voltage | 5V DC power supply |
| Control interface | Smart Wi-Fi web portal (Android, iOS, laptop) |
| Size options | 25×20, 25×40, 50×20, 50×40, 100×20 (select from the dropdown above) |
Quick Start Guide
Step 1 — Connect to the controller
- Connect your 5V power supply to the controller and plug in your LED strings.
- Open the Wi-Fi settings on your phone or laptop.
- Find the network named W1000_20P_... (for example, W1000_20P_A1B2).
- Connect and enter the default password: 12341234
Step 2 — Open the control panel
- Open any web browser (Chrome, Safari, etc.).
- In the address bar type 10.10.10.1 and press Enter.
- The Koshi Electronics control panel loads instantly.
Step 3 — Using the control panel
- Text: type your message (English, Hindi, and regional languages). Set text direction to NORMAL for most languages, or URDU/ARABIC for right-to-left scripts. Choose font style/size and adjust vertical position.
- Colours: pick custom text and background colours, or tap RAINBOW TEXT for a multi-colour cycling effect.
- Playback mode: TEXT ONLY, TEXT + ANIMATIONS, or ANIMATIONS ONLY. Adjust brightness (10–100%) and set text-scroll and animation speeds independently.
- Hardware setup: tell the panel where your first LED string connects (usually TOP LEFT or TOP RIGHT) so text never displays upside down.
Step 4 — Send to display
When you're happy with the settings, scroll down and press SEND TO DEVICE. Your board updates instantly.
Troubleshooting & Tips
- Forgot the Wi-Fi password? With the controller powered on, press and hold the physical BOOT/RESET button for 8 seconds. The lights flash and the password resets to 12341234.
- "No internet connection" warning? This is normal — the W1000 network has no internet. Tap "Keep Connected" / "Stay Connected" so your phone stays linked while you change the lights.
Kya isme koi app download karni padti hai?
Nahi. Koi app download nahi karni. Controller ON karo, phone ke WiFi mein W1000_20P_XXXX network se connect karo (password: 12341234), phir browser mein 10.10.10.1 type karo — control panel seedha phone mein khul jaata hai.
Kaunsi languages support karta hai?
Hindi, English, Urdu, Arabic (right-to-left), Marathi, Gujarati, Tamil aur baaki regional languages — sabhi display hoti hain. Urdu/Arabic ke liye direction setting change karo.
Z-type wiring kya hoti hai?
Z-type wiring mein LED strings parallel chalti hain — seedhi line mein, ek ke baad ek. Isse bada LED board banana bahut aasaan hota hai aur animation bilkul smooth chalta hai, koi lag nahi.
Text aur background colour kaise change karein?
Control panel mein Text Color aur BG Color ke boxes par tap karo — colour picker se apna pasandida colour chunno. Rainbow Text button se automatically multicolour effect bhi chalu ho jaata hai.
Speed aur brightness kaise adjust karein?
Control panel mein Brightness slider se LED ki roshni 10% se 100% tak set karo. Speed slider se text scrolling aur animation dono ki speed alag-alag control hoti hai.
Password bhool gaye to kya karein?
Controller ON rakhein aur board par BOOT/RESET button ko 8 second tak dabaye rakhein — LEDs flash karengi aur password wapas default 12341234 ho jaayega.
Phone mein 'No Internet' warning aa rahi hai to kya karein?
Ye bilkul normal hai. W1000 network internet nahi deta — sirf controller se connect karta hai. Phone mein 'Keep Connected' ya 'Stay Connected' dabao taaki phone disconnect na ho.
